• Contact Resistance：100mΩ max
• Insulation Resistance：100MΩmin.500VDC
• Dielectric Strength：250VAC/1 min
• Electrical Life：500,000cycles min
• Storage Temperature：-30℃ to +80℃
• Contact Arrangement：1 pole 1throw
|
 |
   |
| Part Number | Contact Resistance | Insulation Resistance | Dielectric Strength | Electrical Life | Storage Temp | Contact Arrangement | PDF下載 |
|---|---|---|---|---|---|---|---|
| RTSMW-6 | 100mΩ max | 100MΩmin.500VDC | 250VAC/1 min | 500,000cycles min | -30℃ to +80℃ | 1 pole 1throw | 暫無 |
| RTSJW-6 | 100mΩ max | 100MΩmin.500VDC | 250VAC/1 min | 500,000cycles min | -30℃ to +80℃ | 1 pole 1throw | 暫無 |
| RTSHW-6 | 100mΩ max | 100MΩmin.500VDC | 250VAC/1 min | 500,000cycles min | -30℃ to +80℃ | 1 pole 1throw | 暫無 |
| RTSUW-6 | 100mΩ max | 100MΩmin.500VDC | 250VAC/1 min | 500,000cycles min | -30℃ to +80℃ | 1 pole 1throw | 暫無 |
