• Rating：12VDC 50mA
• Contact Resistance：100mΩ Max
• Insulation Resistance：100MΩ min(250VDC)
• Dielectric Strength：250VAC 50/60Hz FOR 1 min
• Operating Force：160±50g
• Electric Life：100,000 cycles
• Operating Temperature Range：-20℃ ~ + 70℃
• Travel：0.25±0.1 mm
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electric Life | Operating Temperature Range | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R592-1L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592-1 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592-1ML(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592-1M | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1ML(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1M | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-102L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-102 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-108L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-108 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1013L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1013 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1010L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1010 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1014L(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1014 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-101ML(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-101M | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-102ML(With LED) | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-102M | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-108M | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-108ML | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1013M | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-1013ML | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-111 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-111L | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-112 | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
| R592B-112L | 12VDC 50mA | 100mΩ Max | 100MΩ min(250VDC) | 250VAC 50/60Hz FOR 1 min | 160±50g | 100,000 cycles | -20℃ ~ + 70℃ | 0.25±0.1 mm | 暫無 |
